Flexible Ceramic Tile-006
Binmao
Flexible Ceramic Tile-006
The Architectural Flexible Ceramic Cladding System combines modern composite materials with high-performance ceramic technology to deliver a versatile façade and interior surface solution.
Developed for architects, façade engineers, and contractors, this system offers the tactile appeal of natural ceramic with superior flexibility and reduced structural load.
Each panel is a multilayer composite of mineral-based ceramic and polymer reinforcement, achieving a bending radius of 200–300 mm without cracks or deformation. The lightweight design (3–6 kg/m²) enables easy handling and installation on both new builds and retrofitted façades.
Engineered to meet international fire, UV, and impact resistance standards, it’s ideal for demanding architectural applications — from complex façades and soffits to interior feature walls and columns.
Available in a variety of textures and finishes (stone, concrete, matte, metallic), the system provides creative freedom while maintaining structural reliability and long-term weather resistance.
Comprehensive project support — including CAD/BIM files, installation manuals, and performance certifications — ensures seamless specification and delivery for large-scale architectural projects.
Product Advantage |
Ultra-thin flexible ceramic composite (3–5 mm typical)
Bendable up to 200–300 mm radius for curved façades
Lightweight: 3–6 kg/m², reducing structural load
Class A fire performance; non-combustible and low smoke emission
Weather, frost, and UV resistant for exterior durability
Scratch and impact resistant surface
Compatible with both adhesive and mechanical installation systems
Customizable surface finishes — stone, concrete, metallic, matte
Curved façades and complex architectural envelopes
Interior feature walls and column cladding
High-rise and modular building exteriors
Commercial, hospitality, and institutional projects
Renovation and over-cladding applications
Lightweight panels for prefabricated or transport-sensitive projects
| Item | Description |
|---|---|
| Material | Flexible ceramic composite |
| Thickness | 3 mm / 4 mm / 5 mm |
| Standard Size | 1200×600 mm / 2400×1200 mm / custom sizes |
| Weight | 3.0–6.0 kg/m² |
| Bend Radius | 200–300 mm |
| Water Absorption | ≤1% |
| Fire Rating | EN 13501-1 Class A1 / ASTM E84 Class A |
| Surface Finishes | Stone / Concrete / Matte / Metallic |
| Temperature Resistance | -40°C to +90°C |
| Packaging | Protective interleaving + reinforced export crates |
Substrate Check: Ensure clean, dry, and stable surface meeting structural tolerances.
Fixing System: Compatible with flexible adhesive or mechanical concealed systems.
Panel Layout: Follow grid lines and expansion joint design.
Bonding & Curing: Apply uniform adhesive coverage; allow proper curing time.
Inspection: Verify flatness, joint width, and alignment before final sealing.
Finishing: Clean with pH-neutral agent and seal joints if specified.
Architectural-Grade Engineering: Certified to EN/ASTM façade performance standards.
Project Support: Technical consultation, BIM/CAD resources, and on-site guidance.
Structural Advantage: Up to 70% lighter than stone or traditional ceramic.
Customization: CNC cutting, radius shaping, pre-finished edges.
Tested Durability: Fire, UV, impact, and weather resistance verified.
Sustainability: Low carbon footprint and recyclable components, supporting LEED/BREEAM credits.
