Acoustic wall panel 009
Binmao
Acoustic wall panel 009
Binmao Acoustic Wall Panel 009 integrates advanced acoustic engineering with modern interior aesthetics, delivering quiet, comfortable environments across diverse spaces. Designed for commercial contractors, bulk purchasers and project managers, this panel addresses core noise control challenges while meeting global building and safety standards.
Parameter | Details |
|---|---|
Finish | PVC / Wood Veneer |
Material | MDF Board / Black HDF Board + PET (Polyester) |
Eco-certifications | CARB P2 / E1 |
Fire Resistance | EN 13501-1 Class B, ASTM E84 Class A (customization required) |
Installation Method | Screws or adhesive |
Noise Reduction Coefficient | NRC 0.8 |
Customization | Fully supported |
Patent Status | Patented acoustic structure design |
The dual-layer structure of black HDF board and 12mm PET polyester fiber core creates a porous sound-absorbing matrix that traps sound waves rather than reflecting them. This design reduces mid-to-high frequency echoes by 80% and blocks airborne sound transmission, effectively lowering background noise levels in enclosed spaces.
Panels feature a standardized modular format compatible with standard drywall framing systems. Install using screws spaced 300mm×300mm with 2-3mm joint gaps, or apply adhesive for seamless surfaces. This system cuts installation time by 40% compared to traditional acoustic treatments and requires no specialized tools.
All raw materials meet strict formaldehyde emission standards set by CARB P2 and E1 regulations. Panels emit negligible levels of volatile organic compounds, making them suitable for 24/7 occupied spaces including offices, classrooms and residential bedrooms.
Panels comply with EN 13501-1 Class B fire safety requirements for commercial interiors. ASTM E84 Class A fire rating is available upon custom request, ensuring alignment with both EU and US building codes.
The engineered board core resists moisture absorption and dimensional changes across varying temperature and humidity levels, maintaining structural integrity in diverse environmental conditions.
Office & Conference Rooms: Protect confidential discussions and improve speech clarity by 35%. Panels eliminate reverberation that distorts verbal communication, ensuring every participant is heard without disturbing adjacent work areas.
Recording Studio & Podcast Rooms: Create controlled acoustic environments with minimal sound reflection. Achieve broadcast-quality recordings by reducing unwanted background noise and standing waves.
Classroom & Training Centers: Optimize reverberation time to 0.6-0.8 seconds, the optimal range for learning. This improves teacher voice projection and student focus, enhancing overall educational outcomes.
Hotel, Restaurant & Bar Spaces: Reduce cross-table noise and create quiet, comfortable leisure environments that improve guest satisfaction and extend stay durations.
Residential Spaces: Transform bedrooms, home theaters and living rooms into private, peaceful retreats free from external noise disturbances.
We offer comprehensive customization for large-scale projects, including custom panel sizes, 12 standard color options and custom color matching. Choose between PVC or wood veneer finishes to align with your interior design requirements. Our engineering team can also develop tailored acoustic solutions for unique project specifications.
All panels undergo rigorous third-party testing and hold CARB P2, E1 and EN 13501-1 Class B certifications. Our patented acoustic structure design optimizes fiber density for balanced sound absorption and structural performance, setting our products apart from standard acoustic panels.
With 10+ years of specialized experience in acoustic material manufacturing, we have completed 500+ commercial projects across 30+ countries. Our factory maintains a monthly production capacity of 10,000㎡, with 7-15 day lead times for standard orders and 20-30 days for custom orders. We provide a 2-year warranty against manufacturing defects and offer full technical support throughout the installation process.
The minimum order quantity is 50㎡ for standard panels and 100㎡ for custom orders.
Yes, we offer detailed installation manuals and remote technical support for all projects.
Free samples are available upon request; international shipping costs apply.
Request a free detailed quote or product sample today. Our acoustic engineering team will respond to all inquiries within 24 business hours.
